The BD16952EFV is an AEC-Q100 automotive qualified 2-channel Half-Bridge Gate Driver,controlled by an external MCU through a 16-bit Serial Peripheral Interface(SPI).Independent control of low-side and high-side N-MOSFETS allows for several MCU controlled modes.A programmable drive current is available to adjust slew-rates,in order to meet EMI and power dissipation requirements.Diagnostics can be read and reset by an external MCU.

特性

•AEC-Q100 Qualified

•2ch Half-Bridge Gate Drivers

•4 external MOSFETs are Controlled Independently

•Half-Bridge Control Modes are Selected by SPI

•Slew Rates are Controlled with Constant Source/Sink Current.

•500 kHz Oscillation for Charge Pump.

•16bit SPI
