The AMC7932 is a highly integrated analog monitor and control device designed for high-density,general-purpose monitor and control systems.The AMC7932 includes 32 12-bit,digital-to-analog converters(DACs)with programmable output ranges.The device also incorporates a multiplexed,12-bit analog-to-digital converter(ADC)with programmable threshold detectors,a temperature sensor,and an internal reference.The AMC7932 high level of integration significantly reduces component count and simplifies closed-loop system designs,thus making it a great choice for high-density applications where board space is critical.

The device includes flexible input/output(FlexIO)pins that can be configured as either analog inputs to the ADC or as GPIOs with two available options:AMC7932(six FlexIO pins)and AMC7932F(five FlexIO pins).Communication to the device is performed through a 3-wire(AMC7932)or 4-wire(AMC7932F)SPI-compatible interface.

The AMC7932 high-integration and wide operating temperature range make the device an excellent choice as an all-in-one,bias-control circuit for the power amplifiers(PA)found in multichannel RF communication systems.The flexible DAC output ranges and built-in sequencing features allow the device to be used as a biasing controller for a large variety of transistor technologies,such as LDMOS,GaAs,and GaN.
